Contribution to the fauna of Tydeidae (Acari: Prostigmata) from Western Siberia, Russia

Khaustov, Alexander A. ¹

¹✉ Institute of Environmental and Agricultural Biology (X-BIO), Tyumen State University, Tyumen, Russia.

2023 - Volume: 63 Issue: 2 pages: 491-521

https://doi.org/10.24349/7fyj-me9u
ZooBank LSID: 8740CE42-9AD6-4E17-81EF-DBCF00AD1EC8

---

Original research

Keywords

Tydeoidea, Tydeinae, systematics, morphology, Palearctic, mites, Asia

Abstract

---

Introduction

The family Tydeidae is a diverse group of mites distributed worldwide and currently includes about 31 genera and more than 300 species (Silva et al. 2016; Kaźmierski et al. 2018; André 2021; Khaustov 2022). Most tydeid mites are fungivorous, however some species are predators of small arthropods, phytophagous and scavengers (Walter et al. 2009). The scientific history of tydeid mites and current state of knowledge in taxonomy are discussed in Kaźmierski (1998), Silva et al. (2016) and André (2021). The tydeid mites of Asian Russia are almost completely unstudied with only two papers describing three new species of Lorryia sensu Kaźmierski, 1989 (Kaźmierski 2008) and a new genus and species, Andrelorryia hajiqanbari Khaustov, 2022 (Khaustov 2022). In addition, Kaźmierski (2000) reported Lorryia woolleyi and L. maga from Tuva Republic in Russia.

This study provides a review of Tydeidae collected in Tyumen and Kurgan Regions of Western Siberia, Russia.

Material and methods

Mites were extracted from various samples (soil, litter, bark of trees, etc.) using Berlese funnels. All mites were mounted in Hoyer's medium. Mite morphology was studied using a Carl Zeiss AxioImager A2 compound microscope with phase contrast and differential interference contrast (DIC) illumination. Notation applied to the body and leg setae follow the system of Grandjean, overviewed by Kethley (1990) and André (1981b), respectively; palpal setation follows André (1981a). The diagnosis of the genus Lorryia follows Kaźmierski (1989). Photomicrographs were taken with an AxioCam ICc5 digital camera. For SEM microscopy several alcohol-preserved mites were dried in a JFD 320 freeze drying device (JEOL, Japan), dusted with gold and scanned with a JEOL–JSM-6510LV and TESCAN Mira3 LMU SEM microscopes. All measurements are given in micrometers (μm) for the holotype and for five paratypes (in parentheses).

Additional materials examined for the comparison with collected species:

1. Lorryia polygonata Kulczycki, 1992: four females, Ukraine, Kharkov Region, Lozovaya District, Novoivanovka village, on bark of apple tree, 4 July 1993, coll. A.A. Khaustov.
2. Lorryia polita Kuznetsov, 1975: female holotype, Georgia, vicinity of Tbilisi, in moss, 17 March 1959, coll. L.A. Gomelauri.
3. Paralorryia formosa Livshitz, 1972: female holotype, Crimea, Sevastopol (Khersones), on Ephedra distachya L., 29 April 1968, coll. I.Z. Livshitz.

Systematics

Family Tydeidae

Subfamily Tydeinae

Genus Lorryia Oudemans, 1925 sensu Kaźmierski, 1989

Type species: Lorryia superba Oudemans, 1925, by original designation.

Lorryia sibiriensis n. sp.

ZOOBANK: A6FED4F0-35C4-4A9E-8701-1B58A77292CF

(Figs 1–8)

Description

Female — (Figs 1–3, 5–7, 8A–C). Body ovate (Figs 5A, 7). Length of idiosoma 355 (315–360), maximum width 270 (235–270).

Idiosomal dorsum – (Figs 1A, 5, 7A, 8A). Dorsal ornamentation type ''Lorryia''; reticulation forms discrete areas divided by striated integument as illustrated on Figs 1A, 5A and 7A; reticulation meshes irregular in shape (Figs 5C, 8A); cross-ties ''Y''-shaped, rarely ''X''-shaped, frames of meshes with rare ''I''-shaped costulae oriented longitudinally (Fig. 5D). Dorsal hysterosomal setae subequal in length and shape, curved, weakly blunt-tipped and weakly barbed (Fig. 5D); setae vi, ve and sce with more attenuate tips than hysterosomal setae; trichobothria smooth, whip-like, about three times longer than other dorsal setae. Only cupuli ia hardly discernible inside polygonal cells, other cupuli not evident. Lengths of setae: vi 17 (16–18), ve 20 (20–21), sci 65 (60–70), sce 23 (21–23), c1 21 (20–22), c2 22 (21–23), d 23 (21–23), e 21 (20–23), f1 23 (22–24), f2 23 (22–24), h1 23 (20–23), h2 23 (22–24), ps1 20 (19–21).

Idiosomal venter – (Figs 1B, 6A, B, 7B, 8B, C). Ventral surface mostly striated; striae between setae 3a and 4a more or less ''V''-shaped (Fig. 8B); some striae mesad bases of setae g2–g4 without tubercles (Fig. 6A). Coxal organ small, ovate (Fig. 6B). Ventral setae smooth and pointed, except ps1 with same shape as dorsal setae; in female holotype seta ps1 unpaired (Fig. 7B). Six pairs of genital setae (Fig. 6A). Two pairs of round genital papillae clearly visible inside progenital chamber (Fig. 8C).

Gnathosoma – (Figs 2, 6C). Gnathosoma usually completely covered by idiosoma. Cheliceral stylets 16 (16–17), longer than palptarsus 10 (10–11) and combined length of palptarsus and eupathidiun (p) 14 (14–15). Palpal terminal eupathidium very short, thick in basal part and slightly narrowed distally, with rounded tip; seta d bifurcates distally; seta acm blunt-tipped. All palpal setae smooth. Subcapitulum (Figs 2B, 6C) with smooth and pointed subcapitular setae (sc1, sc2) and two pairs of short smooth and pointed adoral setae (or1, or2). Gnathosomal supracoxal setae ep rod-like.

Legs – (Figs 3, 6D). Empodia with small empodial hooks; tarsal claws serrate (Fig. 6D). Leg I (Figs 3A, 6D). Setae (p), (tc) and ft″ of tarsus eupathid-like, smooth and longitudinally striated (Fig. 6D); setae d of femur, (l) of genu and d of tibia similar to dorsal idiosomal setae, other setae pointed and weakly barbed. Solenidion ω 8 (7–8) baculiform; famulus k on tibia multibranched distally. Leg supracoxal seta (el) rod-like, located dorsally near trochanter. Leg II (Fig. 3B). Setae d of femur, (l) of genu, d and v′ of tibia similar to dorsal idiosomal setae, other leg setae pointed and weakly barbed. Solenidion ω 5 (4–5) baculiform. Leg III (Fig. 3C). Setae d of femur, l′ of genu and d of tibia similar to dorsal idiosomal setae, other leg setae pointed and weakly barbed. Leg IV (Fig. 3D). Setae l′ of genu and d of tibia similar to dorsal idiosomal setae, other leg setae pointed and weakly barbed.

Male — Similar to female and differs only in having longitudinal slit-like genital opening and four pairs of short and barbed eugenital setae (Figs 4, 8D). Two pairs of round genital papillae clearly visible inside progenital chamber (Fig. 8D).

Larva, protonymph, deutonymph and tritonymph unknown.

Type material

Female holotype, slide ZISP T-Tyd-002, Russia, Tyumen Region, city of Tyumen, 57°09′N 65°27′E, in moss on bark of birch Betula pendula, 07 May 2014, collected by A.A. Khaustov; paratypes: 3 females, 5 males, same data; 31 female, 1 male, same locality and habitat, 12 May 2019; 1 female, 6 males, Russia, Tyumen Region, Tyumen District, vicinity of Malinovka village, 57°05′N 65°03′E, in moss on bark of aspen Populus tremula L., collected by A.A. Khaustov.

Type deposition

The holotype, one female and one male paratype are deposited in the acarological collection of Zoological Institute of RAS, Saint Petersburg, Russia; other paratypes are deposited in the collection of the Tyumen State University Museum of Zoology, Tyumen, Russia.

Etymology

The name of the new species refers to its geographical distribution in Siberia.

Differential diagnosis

The new species closely resembles L. catenulata (Thor, 1931) and L. polita Kuznetsov, 1975a in having ornamentation type ''Lorryia'' with discrete areas separated by striate cuticle and in having a very short palptarsus. The new species differs from both L. catenulata and L. polita in having irregular reticulate meshes (vs. regular, similar in shape in L. catenulata and L. polita), cross-ties ''Y'' or ''X''-shaped, with their ends and ''I''-shaped costulae directed along frames of meshes (vs. cross-ties ''Y''-shaped, their ends and ''I''-shaped costulae directed transversely from frames of meshes in L. catenulata and L. polita), and in having more blunted dorsal idiosomal setae (pointed in L. catenulata and L. polita).

Lorryia speciosa n. sp.

ZOOBANK: 74E8D1C2-F2C9-4E8A-98E5-1D1D70B3382C

(Figs 9–13)

Description

Male — (Figs 9–12, 13F). Body ovate (Fig. 12). Length of idiosoma 355 (335–355), maximum width 235 (225–235).

Idiosomal dorsum – (Figs 9A, 12, 13A). Dorsal ornamentation type ''mountains'' on hysterosomal dorsum and reticulated on prodorsum; reticulation without distinct discrete areas; with transverse depressions anteriad setae f1 and h1. Striae between ''mountains'' with semioval lobes. Dorsal hysterosomal setae subequal in length and shape, curved, distinctly blunt-tipped and weakly barbed (Fig. 13A); trichobothria smooth, whip-like, about two times longer than other dorsal setae. Cupuli well visible, ovoid in shape. Lengths of setae: vi 28 (26–28), ve 28 (26–28), sci 62 (56–62), sce 32 (31–35), c1 31 (30–34), c2 32 (32–34), d 33 (33–36), e 35 (32–35), f1 34 (34–35), f2 35 (33–36), h1 33 (31–34), h2 33 (33–36), ps1 27 (27–28).

Idiosomal venter – (Figs 9B, 13F). Ventral surface mostly striated; striae between setae 3a and 4a ''V''-shaped (Fig. 13B). Coxal organ small, ovate (Fig. 13C). Ventral setae smooth and pointed, except ps1 with same shape as dorsal setae. Six pairs of genital setae, four pairs of eugenital setae. Two pairs of round genital papillae clearly visible inside progenital chamber (Fig. 13F).

Gnathosoma – (Figs 10, 13C). Gnathosoma usually completely covered by idiosoma. Cheliceral stylets 22 (22–23) with short, posteriorly diffuse basal part and long narrow distal part (Fig. 13C), subequal in length with palptarsus 22 (22–23) and shorter than combined length of palptarsus and eupathidium (p) 29 (29–30). Palpal terminal eupathidium with ''T''-shaped projection distally; seta d unusually deeply bifurcated from its base, one of its projections weakly blunt-tipped and with subterminal barbs; seta acm blunt-tipped. All palpal setae smooth. Subcapitulum (Fig. 13C) with smooth and pointed subcapitular setae (sc1, sc2) and two pairs of short smooth and pointed adoral setae (or1, or2). Gnathosomal supracoxal setae ep rod-like.

Legs – (Fig. 11). Empodia with empodial hooks; tarsal claws serrate. Leg I (Fig. 11A). Setae (p), (tc) and ft″ of tarsus eupathid-like, smooth; setae d of femur, (l) of genu and d of tibia similar to dorsal idiosomal setae, other setae pointed and weakly barbed. Solenidion ω 9 (8–9) baculiform; famulus k on tibia multibranched distally. Leg supracoxal seta (el) rod-like, located dorsally near trochanter. Leg II (Fig. 11B). Setae d of femur, (l) of genu, and d of tibia similar to dorsal idiosomal setae, other leg setae pointed and weakly barbed. Solenidion ω 5 (5) baculiform. Leg III (Fig. 11C). Setae d of femur, l′ of genu and d of tibia similar to dorsal idiosomal setae; seta v′ of trochanter blunt-tipped, other leg setae pointed and weakly barbed. Leg IV (Fig. 11D). Setae l′ of genu and d of tibia similar to dorsal idiosomal setae, other leg setae pointed and weakly barbed.

Female — Similar to male and differs only in having different shape of genital aperture (Fig. 13D) and lacking eugenital setae. Two pairs of round genital papillae clearly visible inside progenital chamber (Fig. 13E).

Larva, protonymph, deutonymph and tritonymph unknown.

Type material

Male holotype, slide ZISP T-Tyd-003, Russia, Kurgan Region, Petuknovsky District, vicinity of lake Medvezh'ye, 55°10′N 67°55′E, soil in steppe, 14 October 2022, collected by A.A. Khaustov; paratypes: 7 females, 4 males, same data.

Type deposition

The holotype, four female and one male paratypes are deposited in the acarological collection of Zoological Institute of RAS, Saint Petersburg, Russia; other paratypes are deposited in the collection of the Tyumen State University Museum of Zoology, Tyumen, Russia.

Etymology

The name of the new species is derived from Latin speciosus meaning beautiful and refers to the very impressive ornamentation of dorsal idiosoma.

Differential diagnosis

The new species strongly resembles L. danhidalgoi Kazmierski, 1998 in having ornamentation type ''mountains'' and lacking discrete reticulate areas on idiosomal dorsum. The new species differs from L. danhidalgoi in having distinctly blunt-tipped dorsal idiosomal setae (vs. pointed in L. danhidalgoi), ''O''-shaped coxal organ (vs. ''8''-shaped in L. danhidalgoi), and in having unusual seta d of palptarsus divided from its base (vs. seta d of palptarsus divided only distally in L. danhidalgoi).

Lorryia evansi Baker, 1968

Lorryia evansi Baker, 1968a, 992, Fig. 16.

Brachytydeus evansi: Silva et al. 2016, 14.

(Figs 14–19)

Redescription

Female — (Figs 14–18, 19A, B). Body ovate (Figs 14A, 17A, 18). Length of idiosoma 255–310, maximum width 185–215.

Idiosomal dorsum – (Figs 14A, 17A–D, 18, 19A). Dorsal ornamentation type ''Lorryia''; reticulation forms discrete areas divided by striated integument as illustrated on Figs 14A, 17A and 18; reticulation meshes regular in shape (Figs 17A–D); cross-ties triangular, rarely quadrangular in shape, frames of meshes with rare ''I''-shaped transversely aligned costulae. Dorsal hysterosomal setae subequal in length and shape, slightly curved, blunt-tipped, smooth or with very small serration on dorsal surface of setae; setae h1, h2 and ps1 slightly thicker and more blunt than other dorsal setae; trichobothria smooth, weakly blunt-tipped (sometimes pointed), about two times longer than other dorsal setae. All cupuli ovoid. Lengths of setae: vi 27–30, ve 30–34, sci 45–59, sce 32–34, c1 29–34, c2 31–36, d 28–32, e 31–34, f1 31–33, f2 30–34, h1 28–32, h2 31–33, ps1 22–28.

Idiosomal venter – (Figs 14B, 19B). Ventral surface mostly striated; striae between setae 3a and 4a longitudinally parallel (Fig. 19B). Coxal organ ''8''-shaped. Ventral setae smooth and pointed, except ps1 which of the same shape as dorsal setae. Six pairs of genital setae. Genital papillae not evident.

Gnathosoma – (Figs 15, 17E). Gnathosoma usually completely covered by idiosoma or distal part of chelicerae visible from above. Cheliceral stylets 18–20 subequal in length with palptarsus 17–19 and shorter than combined length of palptarsus and eupathidiun (p) 25–27. Palpal terminal eupathidium with ''T''-shaped tip; seta d bifurcates distally; seta acm blunt-tipped. All palpal setae smooth. Subcapitulum (Fig. 17E) with smooth and pointed subcapitular setae (sc1, sc2) and two pairs of short smooth and pointed adoral setae (or1, or2). Gnathosomal supracoxal setae ep rod-like.

Legs – (Figs 16, 17F). Empodia with small empodial hooks; tarsal claws serrate (Fig. 17F). Leg I (Figs 16A, 17F). Setae (p), (tc) and ft″ of tarsus eupathid-like, smooth and longitudinally striated (Fig. 17F); setae d of femur, (l) of genu and d of tibia similar to dorsal idiosomal setae, other setae pointed and weakly barbed. Solenidion ω 8 baculiform; famulus k on tibia multibranched distally. Leg supracoxal seta (el) rod-like, located dorsally near trochanter. Leg II (Fig. 16B). Setae d of femur, (l) of genu, and d of tibia similar to dorsal idiosomal setae, other leg setae pointed and weakly barbed. Solenidion ω 3–4 baculiform. Leg III (Fig. 16C). Setae d of femur, l′ of genu and d of tibia similar to dorsal idiosomal setae, other leg setae pointed and weakly barbed. Leg IV (Fig. 16D). Setae l′ of genu and d of tibia similar to dorsal idiosomal setae, other leg setae pointed and weakly barbed.

Male similar to female and differs only in having longitudinal slit-like genital opening (Fig. 19C) and four pairs of short and barbed eugenital setae.

Larva, protonymph, deutonymph and tritonymph unknown.

Material examined

Sixteen females, 3 males, Russia, Tyumen Region, vicinity of Uspenka village, 57°03′N 65°03′E, in rotting bark of unknown tree, 07 May 2019, collected by A.A. Khaustov.

Remarks

Lorryia evansi was described from quarantine in USA (New York) on cut flowers imported from the Netherlands (Baker 1968a). This species is very similar to L. polygonata Kulczyck1, 1992 described from Ukraine. According to keys provided by Kaźmierski (1998) and Silva et al. (2016), L. evansi differs from L. polygonata only by smooth or rough dorsal idiosomal setae, while in L. polygonata dorsal idiosomal setae clearly serrated. I examined several specimens of L. polygonata collected by me on apple bark in Ukraine. In fact, the dorsal setae in L. polygonata are smooth or rough, not clearly serrated. In the original description of L. polygonata the author also mentioned that most of the setae are smooth or just have few very small barbs apically. However, L. polygonata can be distinguished from L. evansi by distinctly thicker setae f2, h1, h2, and ps1; setae f2 clearly thicker and more blunt than f2 (Fig. 19D); in contrast to subequal in width and shape of setae f1 and f2 in L. evansi (Fig. 19A).

Lorryia catenulata (Thor, 1931)

Retetydeus catenulatus Thor, 1931, 91

Lorryia catenulata: Baker 1968a, 1001

Tydeus catenulata: Momen and Lundqvist 1995, 43

Brachytydeus catenulata: Silva et al. 2016, 12

Brachytydeus catenulatus: André 2021

(Figs 20, 21A, B)

This species originally was described from Norway (Thor 1931). Baker (1968a) redescribed it based on specimens from Ireland. Kaźmierski (1980) redescribed it based on materials from Poland. Kuznetsov and Petrov (1984) recorded this species in Latvia. According to Kuznetsov and Petrov (1984) this species also was recorded in European Russia (Voronezh Region), Georgia and Ukraine. Momen and Lundqvist (1995) reported it from Sweden. Kaźmierski et al. (2018) noted that this species prefers such habitats as moss covering shady rocks in dark needle forests.

Kuznetsov and Petrov (1984) provided an illustration of L. catenulata which, in fact, repeat the illustration of L. polita Kuznetsov, 1975a, a closely related species described from Georgia. Most likely, they consider L. polita as a suspected junior synonym of L. catenulata. According to the key of Kaźmierski (1998) L. polita can be distinguished from L. catenulata in having separate reticulated area A[c2]0[e1] between setae c2 and e. In fact, in the original description of Thor (1931) this area is clearly depicted as well as in redescription of Baker (1968a). My specimens from Western Siberia fully correspond to the description of Thor (1931), especially in having an anterior invagination (poorly developed in some specimens) in the reticulate area A[c2]0[e1] (Figs 20A, 22A). For the separation or possible synonymy of L. polita, I examined the holotype of this species (Figs. 21C, D, 22C, D). Both species are very similar, however, the reticulate area A[c2]0[e1] in L. polita is hardly discernible on the left side and is clearly separated from area Ac2 on the right side of the holotype (Fig. 22D). Therefore, the use of this character for the separation of L. polita and L. catenulata is problematic. The study of palpal setae revealed some minor differences between L. polita and L. catenulata. In L. catenulata seta ba of the palptarsus is very short and blunt-tipped, distinctly shorter than seta acm and seta v is pointed (Fig. 21A, B); in L. polita seta ba is unusually long and thin, pointed, subequal in length with acm, and seta v is clearly blunt-tipped (Fig 21C, D). There are no differences in the shape of dorsal idiosomal setae and structure of reticulate areas on the idiosoma. In L. catenulata, the dorsal idiosomal setae are weakly barbed and pointed (Fig. 20C, D), and in L. polita the dorsal idiosomal setae not so strongly barbed as in the original description. Another character, which could be used for the separation of L. polita from L. catenulata, is the shape of striae between ventral setae 3a and 4a. In L. catenulata striae form a ''V''-shaped ornament (Fig. 22B), while in L. polita striae are parallel (Fig. 22C).

Material examined

Fifteen females, 6 males, Russia, Tyumen Region, city of Tyumen, 57°09′N 65°27′E, in moss on soil in the mixed forest, 23 June 2019, collected by A.A. Khaustov.

Lorryia reticulata Oudemans, 1928

Tydeus reticulatus Oudemans, 1928, 380

Tydeus reticulata: Baker 1947, 227

Lorryia reticulata: Oudemans 1929, 481

Brachytydeus reticulata: Silva et al. 2016, 23

Brachytydeus reticulatus: André 2021

Lorryia bedfordiensis: synonymy by Kaźmierski (1998), 300

Lorryia polaris: synonymy by Kaźmierski (1998), 300

This is one of the most widespread species of Tydeidae and probably cosmopolitan (Kaźmierski 1998). In Russia, it was recorded in European part (Kuznetsov and Petrov 1984).

Mondin et al. (2016) consider L. reticulata as suspected junior synonym of L. superba (type species of Lorryia) and Kaźmierski et al. (2018) consider L. reticulata as a junior synonym of L. superba. However, André (2005) described the history of L. superba and noted that type specimen of this species is lost. Therefore, the synonymy of L. reticulata and L. superba still not clear.

Material examined

One female, 1 male, 5 TN, Russia, Tyumen Region, vicinity of Uspenka village, 57°03′N 65°03′E, in rotting bark of spruce, 08 May 2019, collected by A.A. Khaustov; 2 females, Russia, Tyumen Region, Tyumen District, city of Tyumen, 57°09′N 65°27′E, in rotting bark of dead spruce, 15 June 2019, collected by A.A. Khaustov; 2 females, same locality and date, in tree hole of birch.

Lorryia argutus (Kuznetsov and Petrov, 1979) n. comb.

Tydeus argutus Kuznetsov and Petrov, 1979, 131

This species was described from Latvia (Kuznetsov and Petrov 1979; 1984). Unfortunately, this species was not mentioned in the catalogue of Tydeidae (Silva et al. 2016) and in the latest online database (André 2021). It was originally placed in the genus Tydeus, but according to modern taxonomy of Tydeidae it should be placed in the genus Lorryia sensu Kaźmierski (1989).

This is the first record of L. argutus from Russia.

Material examined

Two females, 3 males, Russia, Tyumen Region, vicinity of Uspenka village, 57°03′N 65°03′E, in moss on soil, 02 October 2017, collected by A.A. Khaustov.

Lorryia obstinata (Livshitz, 1973)

Tydeus obstinatus Livshitz, 1973, 49

Lorryia obstinata: Kaźmierski 1998, 336

Brachytydeus obstinata: Silva et al. 2016, 20

Brachytydeus obstinatus: André 2021

This species was described from Crimea (Kuznetsov and Livshitz 1973a). It was also recorded from Latvia and Lithuania (Kuznetsov and Petrov 1984), Poland (Kaźmierski et al. 2018), Iran (Sadeghi et al. 2012), Sweden (Momen and Lundqvist 2005).

Material examined

One female, Russia, Tyumen Region, vicinity of Uspenka village, 57°03′N 65°03′E, in rotting grass on the field, 18 October 2017, collected by A.A. Khaustov; 1 female, Russia, Tyumen Region, Berdyuzhsky District, vicinity of lake Solenoe, 55°42′35.0″N 68°42′49.0″E, soil in steppe, 20 June 2020, collected by A.A. Khaustov.

Lorryia arkadiensis Panou and Emmanouel, 1995

Lorryia arkadiensis Panou and Emmanouel, 1995a, 217

Brachytydeus arkadiensis: Silva et al. 2016, 10

This species was described from Greece (Panou and Emmanouel 1995a). It was also recorded from Poland (Kaźmierski 1998; Laniecki et al. 2021).

This is the first record of L. arkadiensis in Russia.

Material examined

Seven females, 3 males, Russia, Tyumen Region, vicinity of Uspenka village, 57°03′N 65°03′E, in moss on the edge of the pine forest, 6 May 2019, collected by A.A. Khaustov; 3 females, Russia, Tyumen Region, city of Tyumen, 57°09′N 65°27′E, in soil, 04 May 2019, collected by A.A. Khaustov.

Lorryia filiformis (Momen and Lundqvist, 1996)

Tydeus filiformis Momen and Lundqvist, 1996, 89

Lorryia fusiformis: Kaźmierski 1998, 327

Brachytydeus fusiformis: Kaźmierski 2009, 80.

This species was described from Sweden (Momen and Lundqvist 1996). It was also recorded and redescribed from Poland (Kaźmierski 2009).

This is the first record of L. fusiformis in Russia.

Material examined

Three females, Russia, Tyumen Region, vicinity of Uspenka village, 57°03′N 65°03′E, on bark of pine, 24 June 2019, collected by A.A. Khaustov; 3 females, same locality, on bark of spruce, 2 May 2019.

Lorryia szeptyckii (Kaźmierski, 2009) n. comb.

Brachytydeus szeptyckii Kaźmierski, 2009, 80

This species was described from Poland (Kaźmierski 2009).

It was originally placed in the genus Brachytydeus, but according to modern taxonomy of Tydeidae it should be placed in the genus Lorryia sensu Kaźmierski (1989).

This is the first record of L. szeptyckii from Russia.

Material examined

Two females, 4 males, Russia, Kurgan Region, Zverinogolovskiy District, vicinity of settlement Zverinogolovskoe, 54°26′28.7″N 64°51′21.9″E, in grassy soil, 20 September 2019, collected by A.A. Khaustov.

Lorryia serpettae (Momen and Lundqvist, 2005) n. comb.

Tydeus serpettae Momen and Lundqvist, 2005, 233

Brachytydeus serpettae: Silva et al. 2016, 25

This species was described from Sweden (Momen and Lundqvist 2005). It was originally placed in the genus Tydeus, but according to modern taxonomy of Tydeidae it should be placed in the genus Lorryia sensu Kaźmierski (1989).

This is the first record of L. serpettae from Russia.

Material examined

Three females, 2 males, Russia, Tyumen Region, city of Tyumen, 57°09′N 65°27′E, on bark of apple tree, 12 May 2019, collected by A.A. Khaustov.

Lorryia grandiinsignia Kaźmierski, 1991

Lorryia grandiinsignia Kaźmierski, 1991, 339

Brachytydeus grandiinsignia: Silva et al. 2016, 16

Brachytydeus grandiinsignius: André 2021

This species was described from Poland (Kaźmierski 1991).

This is the first record of L. grandiinsignia from Russia.

Material examined

Two females, Russia, Kurgan Region, Zverinogolovskiy District, vicinity of settlement Zverinogolovskoe, 54°26′28.7″N 64°51′21.9″E, in grassy soil, 20 September 2019, collected by A.A. Khaustov.

Lorryia mirabilis (Kuznetsov, 1973)

Tydeus (Eotydeus) mirabilis Kuznetsov, 1973a, 1578

Eotydeus mirabilis: André 1980, 113

Lorryia mirabilis: Kaźmierski 1989, 301

Lorryia mirabila: Kaźmierski 1998, 336

Brachytydeus mirabila: Silva et al. 2016, 19

Eotydeus mirabilis: André 2021

Tydeus unguis Karg, 1975: synonymy by Kaźmierski 1998, 336

This species was described from Crimea (Kuznetsov 1973a). It was also recorded from Poland (Błoszyk et al. 1994), Germany and Sweden (as Tydeus unguis) (Karg 1975; Momen and Lundqvist 1996).

Material examined

Two females, Russia, Tyumen Region, vicinity of lake Kuchak, 57°21′N 66°02′E, in moss, 04 July 2014, collected by A.A. Khaustov.

Lorryia subularoides Kaźmierski, 1989

Lorryia subularoides Kaźmierski, 1989, 293

Brachytydeus subularoides: Silva et al. 2016, 26

This species was described from Poland and Czech Republic (Kaźmierski 1989). It was also recorded from Iran (Darbemamieh et al. 2021).

This is the first record of L. subularoides in Russia.

Material examined

Two females, Russia, Tyumen Region, vicinity of Uspenka village, 57°03′N 65°03′E, in rotting log, 02 May 2019, collected by A.A. Khaustov.

Lorryia paravarsoviensis (Momen and Lundqvist, 1996)

Tydeus paravarsoviensis Momen and Lundqvist, 1996, 86

Lorryia paravarsoviensis: Kaźmierski 1998, 326

Brachytydeus paravarsoviensis: Silva et al. 2016, 22

This species was described from Sweden (Momen and Lundqvist 1996).

This is the first record of L. paravarsoviensis in Russia.

Material examined

Two females, Russia, Tyumen Region, vicinity of lake Kuchak, 57°21′N 66°02′E, n rotting log, 31 May 2014, collected by A.A. Khaustov; 3 females, Russia, Tyumen Region, city of Tyumen, 57°09′N 65°27′E, in forest litter, 09 June 2019, collected by A.A. Khaustov.

Lorryia maga (Kuznetsov, 1973)

Paralorryia maga Kuznetsov, 1973, 604

Venilia maga: Kuznetsov 1979, 1413

Tydeus maga: Momen and Lundqvist 1995, 53

Lorryia maga: Kaźmierski 1998, 334

Kuznetsovia maga: Kammerer 2006, 269

Brachytydeus maga: Silva et al. 2016, 18

Brachytydeus magus: André 2021

This species was described from Crimea (Kuznetsov and Livshitz 1973b). It was also recorded in Sweden (Momen and Lundqvist 1995), Poland (Laniecki et al. 2021), Iran (Akbari et al. 2015) and Siberia (Kaźmierski 2000). Ueckermann et al. (2019) redescribed this species based on materials from Turkey.

Material examined

One female, Russia, Tyumen Region, vicinity of lake Kuchak, 57°21′N 66°02′E, moss on soil in pine forest, 31 May 2014, collected by A.A. Khaustov; 2 females, 2 males, 2 TN, Russia, Kurgan Region, Petuknovsky District, vicinity of lake Medvezh'ye, 55°10′N 67°55′E, soil in steppe, 14 October 2022, collected by A.A. Khaustov.

Lorryia opifera (Kuznetsov, 1973)

Paralorryia opifera Kuznetsov, 1973, 16

Lorryia opifera: Kaźmierski 1998, 333

Brachytydeus opifera: Silva et al. 2016, 21

Brachytydeus opiferus: André 2021

This species was described from Crimea (Kuznetsov and Livshitz 1973c). It was also recorded in Poland (Kaźmierski 2000; Laniecki et al. 2021).

Material examined

Two males, Russia, Tyumen Region, vicinity of Uspenka village, 57°03′N 65°03′E, in soil, 08 May 2019, collected by A.A. Khaustov.

Lorryia livshitzi (Kuznetsov, 1974)

Paralorryia livshitzi Kuznetsov, 1974, 1092

Lorryia livshitzi: Kaźmierski 1998, 333

Brachytydeus livshitzi: Silva et al. 2016, 17

This species was described from Lipetsk region of Russia (Kuznetsov 1974). It was also recorded from Poland (Kaźmierski 2000), Iran (Akbari et al. 2015) and Turkey (Ueckermann et al. 2019).

Material examined

Two females, Russia, Kurgan Region, Petuknovsky District, vicinity of lake Medvezh'ye, 55°10′N 67°55′E, soil in steppe, 14 October 2022, collected by A.A. Khaustov; 1 female, Russia, city of Tyumen, 57°09′N 65°33′E, moss on bark of poplar, 13 April 2020, collected by A.A. Khaustov.

Lorryia woolley (Baker, 1968b)

Paralorryia woolleyi Baker, 1968b, 1103

Lorryia woolleyi: Kaźmierski 1998, 332

Brachytydeus woolleyi: Silva et al. 2016, 15

This species was described from the USA (Baker 1968b). It was also recorded in Poland, Bulgaria, Russia (including Siberia) (Kaźmierski 2000; Kaźmierski et al. 2018), and Iran (Akbari et al. 2015).

Material examined

Nineteen females, Russia, city of Tyumen, 57°09′N 65°33′E, moss on bark of poplar, 13 April 2020, collected by A.A. Khaustov.

Genus Calotydeus Oudemans, 1937

Type species: Calotydeus croceus (Linnaeus) sensu Oudemans, 1928, by original designation

Calotydeus edwardbakeri (Kaźmierski, 1989)

Pseudolorryia edwardbakeri Kaźmierski, 1989

Calotydeus edwardbakeri: André 2005, 995

This species was described from Poland (Kaźmierski 1989).

This is the first record of C. edwardbakeri in Russia.

Material examined

Two females, 1 TN, Russia, Tyumen Region, vicinity of Uspenka village, 57°03′N 65°03′E, in soil, 02 October 2017, collected by A.A. Khaustov; 4 females, same locality, on the bark of pine, 26 May 2019.

Genus Kuznetsovtydides André, 2021

Type species: Tydides ulter Kuznetsov, 1975, by original designation

Kuznetsovtydides ulter (Kuznetsov, 1975b)

Tydides ulter Kuznetsov, 1975b, 1255

Kuznetsovtydides ulter: André 2021, 1030

This species was described from Crimea (Kuznetsov 1975b). It was also recorded in Poland, Slovakia and Hungary (Kaźmierski 2000).

Material examined

Three male, Russia, Kurgan Region, Zverinogolovskiy District, vicinity of settlement Zverinogolovskoe, 54°26′N 64°51′E, in grassy soil, 20 September 2019, collected by A.A. Khaustov.

Genus Metalorryia André, 1980

Type species: Lorryia armaghensis Baker, 1968a, by original designation

Metalorryia delicata (Kuznetsov, 1971)

Lorryia delicata Kuznetsov, 1971, 1745

Metalorryia delicata: Panou and Emmanouel 1995b, 211

Lorryia cristata Karg, 1975, synonymy by Kaźmierski 1998, 346

This species was described from Georgia (Kuznetsov 1971). It was also recorded in Germany (as Lorryia cristata) (Karg 1975), Greece (Panou and Emmanouel 1995b), and Poland (Kaźmierski 1998).

This is the first record of M. delicata in Russia.

Material examined

One female, Russia, Tyumen Region, Berdyuzhsky District, vicinity of lake Solenoe, 55°42′35.0″N 68°42′49.0″E, soil in steppe, 20 June 2020, collected by A.A. Khaustov.

Genus Neoapolorryia El-Bagoury and Momen, 1990

Type species: Neoapolorryia aegyptica El-Bagoury and Momen, 1990, by original designation

Neoapolorryia regia (Kuznetsov, 1973b)

Lorryia regia Kuznetsov, 1973b, 773

Neoapolorryia regia: Kaźmierski 1998, 351

This species was described from Crimea (Kuznetsov 1973b). It was also recorded in Poland (Kaźmierski 1998).

Material examined

One female, 1 TN, Russia, Kurgan Region, Petuknovsky District, vicinity of lake Medvezh'ye, 55°10′N 67°55′E, soil in steppe, 14 October 2022, collected by A.A. Khaustov.

Genus Nudilorryia Kaźmierski, 1996

Type species: Nudilorryia paraferula Kaźmierski, 1996, by original designation

Nudilorryia obsequens Kaźmierski, 1996

Nudilorryia obsequens Kaźmierski, 1996, 207

This species was described from Germany (Kaźmierski 1996).

This is the first record of N. obsequens in Russia.

Material examined

Three females, Russia, Tyumen Region, vicinity of lake Kuchak, 57°21′N 66°02′E, in nest of Formica rufa, 04 July 2014, collected by A.A. Khaustov.

Genus Paralorryia Baker, 1965

Type species: Lorryia cumbrensis Baker, 1944, by original designation

Paralorryia formosa (André, 1984)

Homeotydeus formosa Andre, 1984

Paralorryia formosa: Kaźmierski 1989, 292

This species was described from Belgium (André 1984).

This is the first record of P. formosa in Russia.

Material examined

One female, Russia, city of Tyumen, 57°09′N 65°27′E, bark of dead birch, 31 May 2020, collected by A.A. Khaustov; 1 female, 1 male, Russia, Tyumen Region, Nizhnetavdinskiy District, vicinity of Tyunevo village, 57°22′N 65°41′E, on bark of linden Tilia cordata,31 May 2020, collected by A.A. Khaustov.

Remarks

Paralorryia formosa (André) is very similar morphologically to Paralorryia formosa Livshitz, 1972. In the original description of P. formosa Livshitz the leg chaetotaxy is not described and its taxonomic position is not clear. I examined the holotype of P. formosa Livshitz and found that, besides striation type ''Paralorryia'', it differs from P. formosa (André) in having two setae on femur III and according to the modern system of Tydeidae P. formosa Livshitz should be placed in the genus Nudilorryia Kaźmierski, 1996, i. e. Nudilorryia formosa (Livshitz, 1972) n. comb.

Genus Tydeus Koch, 1836

Type species: Tydeus spathulatus Oudemans, 1928, designated by ICZN (2008)

Tydeus spathulatus Oudemans, 1928

For synonymy, see André (2021)

This species was described from Italy (André 2005). It was also reported from Hungary (Tempfli et al. 2015).

This is the first record of T. spathulatus in Russia.

Material examined

One male, Russia, Tyumen Region, Tyumen District, vicinity of Malinovka village, 57°05′N 65°03′E, in moss on bark of aspen Populus tremula, collected by A.A. Khaustov.

Tydeus nieuwkerkeni André, 2005

Tydeus nieuwkerkeni André, 2005, 993

This species was described from the Netherlands (André 2005).

This is the first record of T. nieuwkerkeni in Russia.

Material examined

Two females, Russia, Tyumen Region, vicinity of lake Kuchak, 57°21′N 66°02′E, on undetermined plant, 31 July 2018, collected by A.A. Khaustov.

Discussion

The present research revealed a diverse fauna of Tydeidae in Western Siberia. However, there are many still undescribed and unidentified species in my collection, which will be described and reported later. Most of these new species were collected in the Altai Mountains.

During this study, I found well-developed genital papillae in adults of several species of Tydeidae, including Lorryia sibiriensis n. sp., L. speciosa n. sp., L. polita and L. catenulata. According to André (1981a) genital papillae (acetabula) in adults of Tydeidae are present, but hardly discernible. Moreover, I have never seen illustrations of the genital papillae in adults of Tydeidae in any publication. The presence of well-developed genital papillae potentially could be used in taxonomy of Tydeidae, probably in separation of species groups, etc. However, more detailed research of previously described species is necessary.

Acknowledgements

This research was supported by the cooperative agreement No. FEWZ-2021-0004 from the Russian Ministry of Science and Higher Education.

---

References

1. Akbari, A., Haddad Irani-Nejad, K., Khanjani, M., Arzanlou, M., Kaźmierski, A. 2015. A new tydeid species (Acari: Tydeidae) with a key to Brachytydeus species from East Azerbaijan Province, Iran. Syst. Appl. Acarol., 20: 423-430.
2. André, H.M. 1980. A generic revision of the family Tydeidae (Acari: Actinedida). IV. Generic descriptions, keys and conclusion. Ann. Soc. Roy. Zool. Belg., 116: 103-168.
3. André, H.M. 1981a. A generic revision of the family Tydeidae (Acari: Prostigmata). II. Organotaxy of the idiosoma and gnathosoma. Acarologia, 22(1): 31-40.
4. André, H.M. 1981b. A generic revision of the family Tydeidae (Acari: Prostigmata). III. Organotaxy of the legs. Acarologia, 22(2): 165-178.
5. André, H.M. 1984. Tydeinae (Acari: Tydeidae) from Belgium I. The genus Homeotydeus. Bull. Ann. Soc. Roy. Belg. Entomol., 120: 117-122.
6. André, H.M. 2005. In search of the true Tydeus (Acari, Tydeidae). J. Nat. Hist., 39: 975-1001. https://doi.org/10.1080/00222930400002838
7. André, H.M. 2021. The Tydeoidea (Ereynetidae, Iolinidae, Triophtydeidae and Tydeidae) - An online database in the Wikispecies platform. Acarologia, 61(4): 1023-1035. https://doi.org/10.24349/6yc5-1lxw
8. Baker, E.W. 1944. Seis especies de Lorryia (Acarina: Tydeidae). Ann. Inst. Biol. Mexico, 15: 215-222.
9. Baker, E.W. 1947. Notes on the mites of the family Tydeidae (Acarina) with descriptions of two new species. Proc. Entomol. Soc. Wash., 49, 133-136.
10. Baker, E.W. 1965. A review of the genera of the family Tydeidae (Acarina), Adv. Acarol., 2: 95-131.
11. Baker, E.W. 1968a. The genus Lorryia. Ann. Entomol. Soc. Amer., 61: 986-1008. https://doi.org/10.1093/aesa/61.4.986
12. Baker, E.W. 1968b. The genus Paralorryia. Ann. Entomol. Soc. Amer., 61, 1097-1106. https://doi.org/10.1093/aesa/61.5.1097
13. Błoszyk, J., Olszanowski, Z., Kaźmierski, A., Błaszak, C., Niedbała, W. 1994. Wykaz gatunków roztoczy (Acari) rezerwatów grądowych ''Jakubowo'' i ''Las Grądowy nad Mogilnicą'' w zachodniej Wielkopolsce. Parki Narodow. Rezerw. Przyrody, 13: 29-49. [in Polish]
14. Darbemamieh, M., Ahadiyat, A., Farmahiny Farahani, V.R., Sharifian, A. 2021. Iranian checklist of Tydeoidea (Trombidiformes: Prostigmata) until the end of 2020. Internat. J. Acarol., 47(7): 592-602. https://doi.org/10.1080/01647954.2021.1976833
15. El-Bagoury, M.E., Momen, F.M. 1990. Neoapolorryia gen. n. of the family Tydeidae from Egypt (Acari: Tydeoidea). Entom. Mitt. Zool. Mus. Hamb., 138: 25-28.
16. ICZN. 2008. OPINION 2190 (Case 3354). Tydeus KOCH, 1836 (Arachnida, Acari): Tydeus spathulatus OUDEMANS, 1928 designated as the type species. Bulletin of zoological nomenclature 65(1): 68. Reference page. https://doi.org/10.21805/bzn.v65i1.a14
17. Kammerer, C.F. 2006. Notes on some preoccupied names in Arthropoda. Acta Zootaxon. Sin., 31: 269-271.
18. Karg, W. 1975. Zur Kenntnis der Tydeiden (Acarina, Trombidiformes) aus Apfelanlagen. Zool. Anz., 194: 91-110.
19. Kaźmierski, A. 1980. Materials to the knowledge of Tydeidae (Acari, Prostigmata) in Poland. 1. The genus Lorryia Oudemans. In: Materials to the fauna of the Polish mites (Acari). Prace Komis. boil., Poznań, 54: 87-129. [In Polish].
20. Kaźmierski, A. 1989. Revision of the genera Tydeus Koch sensu André, Homeotydeus André and Orthotydeus André with description of a new genus and four new species of Tydeinae (Acari: Actinedida: Tydeidae). Mitt. Hamburg. Zool. Mus. Inst., 86: 289-314.
21. Kaźmierski, A. 1991. Description of two new species of the genus Lorryia sensu Kaźmierski (Acari: Actinedida. Tydeidae). Bull. Polish Acad. Sci., 39: 339-346.
22. Kaźmierski, A. 1996. A revision of the subfamilies Pretydeinae and Tydeinae (Acari, Actinedida: Tydeidae). Part III. Seven new genera and some new species of the Tydeinae, with a generic key. Mitt. Hamb. Zool. Mus. Inst., 93: 199-227.
23. Kaźmierski, A. 1998. Tydeinae of the world: generic relationships, new and redescribed taxa and keys to all species. A revision of the subfamilies Pretydeinae and Tydeinae (Acari: Actinedida: Tydeidae) - part IV. Acta zool. Cracov., 41: 283-455.
24. Kaźmierski, A. 2000. Prostigmatic mites (Acari: Actinedida) from the Słońsk Nature Reserve. Part II: the families Tydeidae, Meyerellidae and Iolinidae of Słońsk area with new data on distribution in Palearctic. Biol. Bull. Poznań, 37(2): 327-341.
25. Kaźmierski, A. 2008. Three new tydeid species of the genus Brachytydeus Thor, 1931 sensu André 2005 (Acari: Actinedida: Tydeidae) from Siberia. Ann. Zool., 58: 347-355. https://doi.org/10.3161/000345409X432619
26. Kaźmierski, A. 2009. Brachytydeus szeptyckii sp. n. (Acari: Actinedida: Tydeidae); a new tydein mite from Poland. Acta Zool. Cracov., 52, 79-85. https://doi.org/10.3409/azc.52b_12.79-85
27. Kaźmierski, A., Marciniak, M., Sikora, B. 2018. Tydeinae mites (Acariformes: Prostigmata: Tydeidae) from bird nests with description of three new species. Syst. Appl. Acarol., 23(5): 803-823. https://doi.org/10.11158/saa.23.5.3
28. Kethley, J. 1990. Acarina: Prostigmata (Actinedida) In: Soil Biology Guide (ed. by D. L. Dindal), pp. 667-753. John Wiley and Sons, New York.
29. Khaustov, A.A. 2022. A new genus and species of Tydeidae (Acari: Prostigmata) from Western Siberia, Russia. Persian J. Acarol, 11(1): 1-10. https://doi.org/10.22073/pja.v11i1.72632
30. KOCH, C.L. 1836. Deutschlands Crustaceen, Myriapoden und Arachniden. Ein Beitrag zur deutschen Fauna, Heft 137. Regensburg, Herrich-Schäffer.
31. Kulczycki, A.G. 1992. A new species of the genus Lorryia (Trombidiformes, Tydeidae) from the Ukraine. Vestn. Zool., 5: 50-56. [in Russian]
32. Kuznetsov, N.N. 1971. Seven species of the genus Lorryia (Tydeidae) from Crimea and Georgia. Zool. Zh., 50(11): 1740-1746. [in Russian]
33. Kuznetsov, N.N. 1973a. A new subgenus and two new species of the family Tydeidae (Acariformes) from Crimea. Zool. Zh., 52(10): 1577-1579. [in Russian]
34. Kuznetsov, N.N. 1973b. Three new species of the genus Lorryia (Tydeidae, Acariformes). Zool. Zh., 52(5): 771-773. [in Russian]
35. Kuznetsov, N.N. 1974. A contribution to the fauna of the family Tydeidae (Acariformes) of the central-chernozem district. Zool. Zh., 53(7): 1092-1093. [in Russian]
36. Kuznetsov, N.N. 1975a. New species of the genus Lor¬ryia (Acariformes, Tydeidae). Zool. Zh., 54(1): 127-130. [in Russian]
37. Kuznetsov, N.N. 1975b. New genus and species of Ty¬deidae (Acariformes) of the Crimean fauna. Zool. Zh., 54(8): 1255-1257. [in Russian]
38. Kuznetsov, N.N. 1979. On revision of the family Ty¬deidae (Acariformes). Zool. Zh., 58(9): 1413-1415. [in Russian]
39. Kuznetsov, N.N., Livshits, I.Z. 1973a. Genus Ty¬deus (Acariformes, Tydeidae) in materials from Crimea and Caucasus. Zool. Zh., 52(1): 45-53. [in Russian]
40. Kuznetsov, N.N., Livshits, I.Z. 1973b. Three new species of the genus Paralorryia (Acariformes, Tydeidae) from the Nikitsky Botanical Gardens. Zool. Zh., 52(4): 604-606. [in Rus¬sian]
41. Kuznetsov, N.N., Livshits, I.Z. 1973c. New and lit¬tle-known species of tydeid mites (Acariformes, Tydeidae) of the Crimean fauna. Biol. Nauki, 3: 13-18. [in Russian]
42. Kuznetsov, N.N., Petrov, V.M. 1979. Rezultaty izucheniya fauny kleschey tidied (Acariformes, Tydeidae) v Pribaltike. Latvijas psr zinatnu aka¬demijas vestis, 4: 130-132. [in Russian]
43. Kuznetsov, N.N., Petrov, V.M. 1984. Predacious mites of the Baltic region (Parasitiformes: Phyto¬seiidae, Acariformes: Prostigmata). Riga, Zinatne, 1-142. [in Russian]
44. Laniecki, R., Kaźmierski, A., Mąkol, J., Laniecka, I., Magowski W. 2021. Know your campus: salient research potential of prostigmatic soil mite fauna (Acariformes: Prostigmata, Endeostigmata) within university campus area. Acarologia, 61(3): 650663. https://doi.org/10.24349/TTpf-5Q3l
45. Livshits, I.Z., Kuznetsov, N.N., Zapletina, V.P. 1972. New species of the family Tydeidae (Acariformes) from Crimea and Azerbaijan. Zool. Zh., 51(10): 1578-1580. [in Russian]
46. Momen, F.M, Lundqvist, L. 1995. The genus Tydeus (Acari: Prostigmata) in Southern Sweden; six new species. Acarologia, 36: 41-53.
47. Momen, F.M., Lundqvist, L. 1996. Corticolous mites; new and unrecorded species of the genus Tydeus (Acari: Prostigmata: Tydeidae) and a key to species of Southern Sweden. Acarologia, 37: 83-96.
48. Momen, F.M., Lundqvist, L. 2005. The genera Metalorryia and Tydeus (Acari: Prostigmata: Tydeidae), new and unrecorded species from south Sweden. Internat. J. Acarol., 31: 225-236. https://doi.org/10.1080/01647950508684425
49. Mondin, A.S., Micalinuvilini, F, Feres R.F. 2016. Four new species of Lorryia (Acari: Tydeidae) associated with Hevea brasiliensis Muell. Arg. (Euphorbiaceae) in Brazil. Zootaxa, 4158(4): 473-490. https://doi.org/10.11646/zootaxa.4158.4.2
50. Oudemans, A.C. 1925. Acarologische Aanteekeningen LXXIX. Entomol. Ber., 7: 26-34.
51. Oudemans, A.C. 1928. Acarologische Aanteekeningen XCIV. Entomol. Ber., 7: 374-382.
52. Oudemans, A.C. 1929. Acarologische Aanteekeningen XCVIII. Entomol. Ber., 7: 476-485.
53. Oudemans, A.C. 1937. Kritisch historisch Overzicht der Acarologie. Derde Gedeelde, Band C. Leiden: E. J. Brill. p I-XXIII, 799-1348.
54. Panou, H.N., Emmanouel, N.G. 1995a. Lorryia arkadiensis, a new species of tydeid mite from Greece (Acari: Prostigmata). Internat. J. Acarol., 21, 217-221. https://doi.org/10.1080/01647959508684061
55. Panou, H.N., Emmanouel, N.G. 1995b. New records of tydeid mites from Greece with description of Lorryia brachypous sp. nov. (Acari: Tydeidae). Entomol. Mitt. Zool. Mus. Hamb., 11: 211-220. https://doi.org/10.1080/01647959508684038
56. Sadeghi, H., Laniecka, I., Kaźmierski, A. 2012. Tydeoid mites (Acari: Triophtydeidae, Iolinidae, Tydeidae) of Razavi Khorasan Province, Iran, with description of three new species. Ann. Zool., 62: 99-114. https://doi.org/10.3161/000345412X633685
57. Silva, G.L., Metzelthin, M.H., Silva, O.S., Ferla, N.J. 2016. Catalogue of the mite family Tydeidae (Acari: Prostigmata) with the world key to the species. Zootaxa, 4135(1): 1-068. https://doi.org/10.11646/zootaxa.4135.1.1
58. Tempfli, B., Penzes, B., Fail, J., Szabo, A. 2015. The occurrence of tydeoid mites (Acari: Tydeoidea) in Hungarian vineyards. Syst. Appl. Acarol., 20: 937-954. https://doi.org/10.11158/saa.20.8.9
59. Thor, S. 1931. Norwegische Tydeidae I-VII, mit Kennzeichnung vier neuer gattungen. Zool. Anz., 94(3/4): 89-104.
60. Ueckermann, E.A., Cobanoğlu, S, Ögreten, A. 2019. Re-description of two new tydeid records (Acari: Trombidiformes) with a key to Tydeoidea species of Turkey. Syst. Appl. Acar., 24(3): 497-507. https://doi.org/10.11158/saa.24.3.13
61. Walter, D.E., Lindquist, E.E., Smith, I.M., Cook, D.R., Krantz, G.W. 2009. Order Trombidiformes. In: Krantz, G.W. and Walter, D.E. (Eds.), A Manual of Acarology. Third Edition. Texas Tech University Press, Lubbock, Texas, pp. 223-420.

---

Please read and follow the instructions to post any comment or correction.
