First report of plant inhabiting predatory mites (Acari: Phytoseiidae) in Maldives

Döker, Ismail 1 ; Khaustov, Vladimir A. 2 and Joharchi, Omid 3

1✉ Institute of Environmental and Agricultural Biology (X-BIO), Tyumen State University, Tyumen, Russia & Cukurova University, Agricultural Faculty, Department of Plant Protection, Acarology Laboratory, 01330, Adana, Turkey.
2Institute of Environmental and Agricultural Biology (X-BIO), Tyumen State University, Tyumen, Russia.
3Institute of Environmental and Agricultural Biology (X-BIO), Tyumen State University, Tyumen, Russia.

2022 - Volume: 62 Issue: 4 pages: 865-878

https://doi.org/10.24349/ocuh-rrin

Original research

Keywords

Indomalayan realm fauna predatory mites new record biological control

Abstract

Although phytoseiid mites are one of the most promising candidates to be used in biological control of mites and insects, nothing is known regarding the native fauna in Maldives. This study reports on six species belongs to four genera for the first time in Maafushi Island, Maldives. Among the species reported, Typhlodromus (Anthoseius) philippinensis and Phytoseius meyerae are re-described and illustrated in detail. In addition, measurements and other diagnostic characters for Amblyseius adhatodae, A. largoensis, Neoseiulus houstoni and T. (A.) neobakeri are provided. Furthermore, the diagnosis of six species improved through including additional morphological characters and new illustrations.


Introduction

Predatory mites of the family Phytoseiidae (Acari: Mesostigmata) have gained a great attention in biological control of spider mites, and small soft bodied insects such as thrips, and whiteflies, in the last quarter of the 20th century (McMurtry et al. 2013).

Maldives is an archipelagic country located in the Indian Ocean in the Indian subcontinent of Asia. Although previous studies have been documented the presence of a series of endemic species in its neighbouring countries such as India and Sri Lanka, nothing isknown about native phytoseiid fauna in Maldives (Gupta 2003; Moraes et al. 2004; Khaustov et al. 2021; Kar and Karmakar 2022).

In this study, six species belong to four genera, Amblyseius adhatodae Muma 1967, A. largoensis (Muma 1955), Neoseiulus houstoni (Schicha 1987), Typhlodromus (Anthoseius) neobakeri Prasad 1968, T. (A.) philippinensis Corpuz 1966, and Phytoseius meyerae Gupta 1977, are reported for the first time in Maldives.

Material and methods

Predatory mites were directly collected from Terminalia catappa L. (Combretaceae) using a camel hair brush and preserved in 70% ethanol. Subsequently, they were cleared in lactic acid and mounted in Hoyer's medium on microscope slides. Species identification, illustrations and measurements were made using a differential interference contrast (DIC) optical system attached a compound microscope Axio Imager A2 (Carl Zeiss, Germany). The dorsal shield length was measured from the anterior to posterior margins along the midline. We followed the taxonomic system of Phytoseiidae proposed by Chant and McMurtry (2007). The nomenclature of setae used follows Lindquist and Evans (1965) as adapted by Rowell et al. (1978) and Chant and Yoshida-Shaul (1991) for the Phytoseiidae. Nomenclature of dorsal solenostomes and poroids follows that of Athias-Henriot (1975). Leg chaetotaxy follows Evans (1963). Measurements are given in micrometers (µm) and presented as mean followed by the range in parenthesis. All mite specimens were collected by the third author. Specimens examined in this study are deposited in the mite collection of Tyumen State University, Zoology Museum, Tyumen, Russia.

Results

New records for Maldives

Amblyseius adhatodae Muma

Amblyseius adhatodae Muma, 1967: 268.

(Figure 1)

Figure 1. Amblyseius adhatodae Muma, 1967 female. a – Ventrianal shield, b – Chelicerae, c – Spermatheca.

Material examined — Three females collected from Maafushi Island, Maldives, 3°56′40.5″N 73°29′35.2″E, Terminalia catappa L. (Combretaceae) in 25 December 2021.

MeasurementsFemale (n = 3) – Length of dorsal shield 338 (328–355), width at level of s4 232 (229–234), width at level of S2 256 (250–262). Seven pairs of dorsal solenostomes (gd1, gd2, gd4, gd5, gd6, gd8 and gd9). Setae measurements as follows: j1 35 (33–38), j3 46 (44–50), j4 5 (4–5), j5 5 (4–5), j6 6 (5–6), J2 6 (5–6), J5 8 (7–8), z2 7 (6–8), z4 8 (7–8), z5 5 (4–6), Z1 10 (10–11), Z4 121 (115–125), Z5 243 (231–261), s4 105 (99–114), S2 10 (10–11), S4 10 (10–11), S5 10, r3 11 (11–12), R1 10 (10–11) and JV5 65 (63–68). Distance between st1-st3 60 (59–61), st2-st2 70 (69–70), st5-st5 67 (64–73); length of ventrianal shield 104 (102–107), width at level of setae ZV2 63 (61–64), width at level of anus 67 (64–70), distance between preanal pores (gv3-gv3) 23 (22–24) (Figure 1a). Fixed cheliceral digit with 11 teeth and pilus dentilis, movable digit generally with four teeth except one specimen with three teeth in one side (Figure 1b). Calyx of spermatheca 36 (35–38) long (Figure 1c). Chaetotaxy of legs as follows: Leg I; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 2 3/1 2/2 2, genu 2 2/1 2/1 2, tibia 2 2/1 2/1 2. Leg II; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 2 3/1 2/1 1, genu 2 2/0 2/0 1, tibia 1 2/1 1/1 1. Leg III; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 1 2/1 1/0 1, genu 1 2/1 2/0 1, tibia 1 1/1 2/1 1. Leg IV; coxa 0 0/1 0/0 0, trochanter 1 0/1 0/2 1, femur 1 2/1 1/0 1, genu 1 2/1 2/0 1, tibia 1 1/1 2/0 1. Length of macrosetae as follows: SgeI 42 (41–44), SgeII 35 (33–36), SgeIII 50 (46–54), StiIII 38 (36–41), StIII 31 (30–33), SgeIV 115 (104–127), StiIV 79 (78–82), StIV 71 (69–73).

World Distribution — Brazil (Lawson-Balagbo et al. 2008), India and Pakistan (Muma 1967), Kenya (Moraes et al. 1989), Sri Lanka (Moraes et al. 2004) and Maldives (this study).

RemarksAmblyseius adhatodae was described by Muma (1967) based on the material collected from Pakistan and India. Morphological characters and measurements of the Maldivian material are almost identical to its original description and redescriptions (Denmark and Muma 1989; Moraes et al. 1989; Moraes et al. 2004; Zannou et al. 2007).

Amblyseius largoensis (Muma)

Amblyseiopsis largoensis Muma, 1955: 266.

(Figure 2)

Figure 2. Amblyseius largoensis (Muma, 1955) female. a – Ventrianal shield, b – Chelicera, c – Spermatheca.

Material examined — Five females collected from Maafushi Island, Maldives, 3°56′40.5″N 73°29′35.2″E, Terminalia catappa L. (Combretaceae) in 25 December 2021.

MeasurementsFemale (n = 5) – Length of dorsal shield 328 (313–345), width at level of s4 206 (190–216), width at level of S2 230 (211–247). Seven pairs of dorsal solenostomes (gd1, gd2, gd4, gd5, gd6, gd8 and gd9). Setae measurements as follows: j1 35 (34–36), j3 48 (45–49), j4 7 (6–7), j5 7 (6–7), j6 8 (7–8), J2 12 (11–12), J5 9 (8–9), z2 11 (10–11), z4 11 (10–11), z5 8 (7–8), Z1 11 (10–12), Z4 83 (80–84), Z5 252 (243–265), s4 87 (83–89), S2 12 (12–13), S4 13 (12–13), S5 13 (12–13), r3 11 (10–11), R1 11 (10–11) and JV5 55 (51–59). Distance between st1-st3 63 (59–67), st2-st2 69 (67–70), st5-st5 70 (69–70); length of ventrianal shield 100 (90–108), width at level of setae ZV2 47 (45–48), width at level of anus 64 (56–67), distance between preanal pores (gv3-gv3) 25 (23–26) (Figure 2a). Fixed cheliceral digit with 9–11 teeth and pilus dentilis, movable digit with three teeth (Figure 2b). Calyx of spermatheca 29 (28–30) long (Figure 2c). Chaetotaxy of legs as follows: Leg I; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 2 3/1 2/2 2, genu 2 2/1 2/1 2, tibia 2 2/1 2/1 2. Leg II; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 2 3/1 2/1 1, genu 2 2/0 2/0 1, tibia 1 2/1 1/1 1. Leg III; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 1 2/1 1/0 1, genu 1 2/1 2/0 1, tibia 1 1/1 2/1 1. Leg IV; coxa 0 0/1 0/0 0, trochanter 1 0/1 0/2 1, femur 1 2/1 1/0 1, genu 1 2/1 2/0 1, tibia 1 1/1 2/0 1. Length of macrosetae as follows: SgeI 37 (35–38), SgeII 33 (32–34), SgeIII 41 (39–43), StiIII 34 (32–37), StIII 32 (30–34), SgeIV 105 (98–112), StiIV 79 (74–83), StIV 61 (58–63).

World Distribution — This species has a cosmopolitan distribution and reported mostly in tropical and subtropical areas of the world (Demite et al. 2022) and Maldives (this study).

Remarks — Morphological characters and measurements of the Maldivian specimens are identical to the original description and subsequent redescriptions (Schicha 1987; Denmark and Muma 1989; Zannou et al. 2007; Navia et al. 2014; Karmakar et al. 2017; Ferragut and Baumann 2019; Liao et al. 2020).

Neoseiulus houstoni (Schicha)

Amblyseius houstoni Schicha, 1987: 111.

(Figure 3)

Figure 3. Neoseiulus houstoni (Schicha, 1987) female. a – Dorsal shield, b – Ventrianal shield, c – Chelicera, d – Spermatheca, e – Leg IV (genu, tibia and basitarsus).

Material examined — Two females collected from Maafushi Island, Maldives, 3°56′40.5″N 73°29′35.2″E, Terminalia catappa L. (Combretaceae) in 25 December 2021.

MeasurementsFemale (n = 2) – Length of dorsal shield 278–288, width at level of s4 140–155, width at level of S2 150–157 (Figure 3a). Six pairs of dorsal solenostomes (gd1, gd2, gd5, gd6, gd8 and gd9). Setae measurements as follows: j1 18–22, j3 33–36, j4 18–19, j5 18–20, j6 22–23, J2 25–28, J5 7, z2 32–33, z4 34–37, z5 21, Z1 28–29, Z4 45–47, Z5 47–50, s4 44–45, S2 42–44, S4 23–25, S5 20–23, r3 32, R1 29–33 and JV5 37–42. Distance between st1-st3 55–56, st2-st2 62–63, st5-st5 62–63; length of ventrianal shield 89–91, width at level of setae ZV2 70–73, width at level of anus 61–63, distance between preanal pores (gv3-gv3) 17 (Figure 3b). Fixed cheliceral digit with three teeth (two apical and one basal) and pilus dentilis, movable digit with one tooth (Figure 3c). Calyx of spermatheca 11–13 long (Figure 3d). Chaetotaxy of legs as follows: Leg I; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 2 3/1 2/2 2, genu 2 2/1 2/1 2, tibia 2 2/1 2/1 2. Leg II; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 2 3/1 2/1 1, genu 2 2/0 2/0 1, tibia 1 2/1 1/1 1. Leg III; coxa 0 0/1 0/1 0, trochanter 1 1/1 0/2 0, femur 1 2/1 1/0 1, genu 1 2/1 2/0 1, tibia 1 1/1 2/1 1. Leg IV; coxa 0 0/1 0/0 0, trochanter 1 1/1 0/2 0, femur 1 2/1 1/0 1, genu 1 2/1 2/0 1, tibia 1 1/1 2/0 1. Length of macrosetae as follows: SgeIV 23, StiIV 18–21, StIV 29–30 (Figure 3e).

World Distribution — Australia (Schicha 1987), Brazil (reported as N. barreti Kreiter by Furtado et al. 2005), Mauritius (Kreiter and Abo-Shnaf 2020), Reunion Island (Kreiter et al. 2020, reported as N. recifensis Gondim Jr. & Moraes, 2001 by Moraes et al. 2012) and Maldives (this study).

RemarksNeoseiulus houstoni was described by Schicha (1987) based on the material collected on Vigna unguiculata (Fabaceae): in Murray Island, Queensland, Australia. Kreiter et al. (2020) recently reported this species from Reunion Island. Based on the examination of the type materials, the authors suggested N. barreti Kreiter in Furtado et al. (2005) and N. recifensis Gondim Jr. & Moraes, 2001 as junior synonyms of N. houstoni. Morphological characters and measurements of the Maldivian specimens are almost identical to the original descriptions and subsequent redescriptions of all three species mentioned above (Schicha 1987; Gondim Jr. and Moraes 2001; Furtado et al. 2005; Kreiter et al. 2020).

Typhlodromus (Anthoseius) neobakeri Prasad

Typhlodromus neobakeri Prasad, 1968: 1369.

(Figure 4)

Figure 4. Typhlodromus (Anthoseius) neobakeri Prasad, 1968 female. a – Dorsal shield, b – Ventrianal shield, c – Chelicera, d – Sternal shield, e – Spermatheca, f – Leg IV (genu, tibia and basitarsus).

Material examined — Five females collected from Maafushi Island, Maldives, 3°56′40.5″N 73°29′35.2″E, Terminalia catappa L. (Combretaceae) in 25 December 2021.

MeasurementsFemale (n = 5) – Length of dorsal shield, 333 (330–334), width at level of s4 163 (160–166), width at level of S2 173 (172–174) (Figure 4a). Five pairs of solenostomes (gd2, gd4, gd6, gd8 and gd9). Setae measurements as follows: j1 18 (16–21), j3 14 (14–15), j4 11 (11–12), j5 12 (11–12), j6 12 (12–13), J2 14 (13–14), J5 10 (10–11), z2 13 (12–14), z3 13 (12–14), z4 14 (14–15), z5 13 (12–14), Z4 19 (18–21), Z5 34 (31–36), s4 16 (15–17), s6 17 (16–18), S2 19 (17–20), S4 22 (22–23), S5 22 (21–24), r3 15 (15–16), R1 17 (16–18) and JV5 31 (28–33). Distance between st1-st2 60 (59–62), st2-st2 55 (55–56) (Figure 4d), st5-st5 54 (53–54); length of ventrianal shield 115 (112–118), width at level of setae ZV2 90 (88–93), distance between preanal pores (gv3-gv3) 15 (15–16) (Figure 4b). Fixed cheliceral digit with four teeth and pilus dentilis, movable digit with two teeth (Figure 4c). Calyx of spermatheca 21 (20–22) long (Figure 4e). Chaetotaxy as follows: Leg I; coxa 0 0/1 0/1 0, trochanter 1 1/1 0/2 1, femur 2 3/1 2/2 2, genu 2 2/1 2/1 2, tibia 2 2/1 2/1 2. Leg II; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 2 3/1 2/1 1, genu 2 2/0 2/0 1, tibia 1 2/1 1/1 1. Leg III: coxa 0 0/1 0/1 0, trochanter 1 1/1 0/2 0, femur 1 2/1 1/0 1, genu 1 2/1 2/0 1, tibia 1 1/1 2/1 1. Leg IV: coxa 0 0/1 0/0 0, trochanter 1 1/1 0/2 0, femur 1 2/1 1/0 1, genu 1 2/0 2/1 1, tibia 1 1/0 2/1 1. Leg IV with one knobbed macroseta, StIV 20 (18–21) in length (Figure 4f).

World Distribution — Australia (Schicha and McMurtry 1986), Brazil (Lofego et al. 2009), Hawaii (Pritchard and Baker 1962), Philippines (Schicha and Corpuz-Raros 1992), USA (Denmark and Evans 2011) and Maldives (this study).

RemarksTyphlodromus (Anthoseius) neobakeri was described by Prasad in 1968 based on the material collected from grass in Waimanalo, Oahu, Hawaii. Morphological characters and measurements of the current specimens almost identical to those of the original description and the re-descriptions (Prasad 1968; Schicha and McMurtry 1986; Schicha and Corpuz-Raros 1992). However, measurements of setae Z4, Z5 and S5 in the Maldivian material are slightly shorter than those provided in the original description, 19 (18–21) versus 24, 34 (31–36) versus 41 and 22 (21–24) versus 26, respectively (Prasad 1968). We considered these differences as intraspecific variations as these measurements fit well with those provided in the redescriptions (Schicha and McMurtry 1986; Lofego et al. 2009). In addition, Schicha and McMurtry (1986) and Schicha (1987) illustrated calyx of spermatheca as tube-like with basal part less sclerotized, based on the material collected from Australia. However, our examinations showed that Maldivian specimens have a nodular atrium which connect a bell-shaped calyx with a neck, as illustrated by Schicha and Corpuz-Raros (1992).

Typhlodromus (Anthoseius) philippinensis Corpuz

Typhlodromus philippinensis Corpuz, 1966: 731.

(Figures 5–6)

Figure 5. Typhlodromus (Anthoseius) philippinensis Corpuz, 1966 female. a – Dorsal shield, b – Ventral idiosoma, c – Chelicera, d – Spermatheca, e – Leg IV (genu, tibia and basitarsus).

Figure 6. Typhlodromus (Anthoseius) philippinensis Corpuz, 1966 female. a – Dorsal shield, b – Ventral idiosoma, c – Chelicera, d – Spermatheca, e – Leg III (genu, tibia and basitarsus), f – Leg IV (genu, tibia and basitarsus).

Material examined — Two females collected from Maafushi Island, Maldives, 3°56′40.5″N 73°29′35.2″E, Terminalia catappa L. (Combretaceae) in 25 December 2021.

MeasurementsFemale (n = 2)Dorsum (Figures 5a, 6a). Dorsal setal pattern 12A:8A (r3 and R1 off shield). Dorsal shield smooth except some lateral reticulations or striations, with five pairs of solenostomes (gd2, gd4, gd6, gd8 and gd9), 14 pairs of visible poroids (id1, id2, id4, id5, idm2, idm3, idm4, idm5, idm6, idx, is1, idl1, idl3 and idl4). Length of dorsal shield 276–291, width at level of s4 160–170, width at level of S2 168–174. Dorsal setae smooth and stout, except Z5 with some barbs and large apical knob. Measurements as follows: j1 18–21, j3 20–23, j4 14, j5 14, j6 17–19, J2 21, J5 9–10, z2 12–16, z3 15–19, z4 19–20, z5 15, Z4 26–30, Z5 40–43, s4 18–21, s6 21–23, S2 22–25, S4 20–22, S5 10–12, r3 15 and R1 16–17. Peritremes long, extending to level of setae j1.Venter (Figures 5b, 6b). Sternal shield smooth, posterior projection present, with three pairs of setae (st1, st2 and st3) and two pairs of pores (iv1 and iv2); distance between st1-st3 56–58, st2-st2 59–60; metasternal setae st4 and pair of pores (iv3) on soft integument; genital shield smooth, width at level of st5 55. Ventrianal shield smooth, pentagonal with four pairs of pre-anal setae (JV1, JV2, JV3 and ZV2), one pair of paraanal (Pa) and one postanal seta (Pst) and with large crescentic preanal pores, distance between pores (gv3-gv3) 16–17. Length of ventrianal shield 86–94, width at level of setae ZV2 76–80. Setae ZV1, ZV3, JV4, JV5 and seven pairs of poroids on integument surrounding ventrianal shield. Setae JV5 smooth with large apical knob, longer than other ventral setae, 28–30 in length.

Chelicera (Figures 5c, 6c). Fixed digit 24–25 long with five teeth and pilus dentilis; movable digit 24–25 long with three teeth.

Spermatheca (Figures 5d, 6d). Calyx saccular, flaring distally 23–24 in length, atrium bulbous directly connected calyx without neck. Major duct broad, minor duct visible.

Legs (Figures 5e, 6e-f). Length of legs (excluding pretarsus): leg I 236–247; leg II 194–215; leg III 195–206; leg IV 250–265. Chaetotaxy as follows: Leg I; coxa 0 0/1 0/1 0, trochanter 1 1/1 0/2 1, femur 2 3/1 2/2 2, genu 2 2/1 2/1 2, tibia 2 2/1 2/1 2. Leg II; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 2 3/1 2/1 1, genu 2 2/0 2/0 1, tibia 1 2/1 1/1 1. Leg III; coxa 0 0/1 0/1 0, trochanter 1 1/1 0/2 0, femur 1 2/1 1/0 1, genu 1 2/1 2/0 1, tibia 1 1/1 2/1 1. Leg IV; coxa 0 0/1 0/0 0, trochanter 1 1/1 0/2 0, femur 1 2/1 1/0 1, genu 1 2/0 2/1 1, tibia 1 1/0 2/1 1. Leg III and IV with modified macrosetae all with large knob. SgeIII 13–15, StiIII 10, SgeIV 20–21, StiIV 10–11, StIV 20 in length. In addition to these setae, leg III and IV have one more modified seta on each segment all blunt-tipped or slightly knobbed.

World Distribution — Philippines (Corpuz 1966) and Maldives (this study).

RemarksTyphlodromus (Anthoseius) philippinensis was described by Corpuz (1966) based on the material collected from Asparagus plumosus (Asparagaceae) in Philippines. Morphological characters and measurements of the Maldivian material are identical to those of the original description and the redescription by Schicha and Corpuz-Raros (1992). However, the authors reported that metasternal plates are present in the Philippine material. We are unable to see and confirm the presence of such structures in our material even with high magnifications (1000X). Therefore, we consider presence/absence of metasternal plates maybe variable or it is somewhat challenging to observe them due to poorly sclerotized sternal area in the current material of this species. As reported by the same authors, on the other hand, T. (A.) philippinensis shows a close affinity to T. (A.) fleschneri Chant, 1960 which was described from Karnataka, India. However, T. (A.) philippinensis can be separated from T. (A.) fleschneri by three teeth on movable digit of chelicera (two in the latter), by having normal peritreme (curved between setae j1 in the latter). Moreover, macrosetae SgeIV and StIV are subequal in length in T. (A.) philippinensis, while StIV at least two times longer than SgeIV in T. (A.) fleschneri (Chant 1960; Swirski and Amitai 1967).

Phytoseius meyerae Gupta

Phytoseius meyerae Gupta, 1977: 7.

(Figures 7–8)

Figure 7. Phytoseius meyerae Gupta, 1977 female. a – Dorsal shield, b – Ventral idiosoma, c – Chelicera, d – Spermathecae, e – Leg IV (genu, tibia and basitarsus).

Figure 8. Phytoseius meyerae Gupta, 1977 female. a – Dorsal shield, b – Genital and ventrianal shields, c – Chelicera, d – Spermatheca, e – Leg IV (genu, tibia and basitarsus).

Material examined — Ten females collected from Maafushi Island, Maldives, 3°56′40.5″N 73°29′35.2″E, Terminalia catappa L. (Combretaceae) in 25 December 2021.

MeasurementsFemale (n = 5)Dorsum (Figures 7a, 8a). Dorsal setal pattern 12A:3A (r3 on shield). Dorsal shield sclerotized and sculptured, with two pairs of visible solenostomes (anterolaterad z5 = gd5) and posteromesad s6 = gd6), nine pairs of visible poroids (id1, id2, id5, id6, idm2, idm4, idx, idl1, and is1). Length of dorsal shield 281 (274–287), width at level of s4 149 (145–151). Dorsal setae thick, and distinctly serrated except j4, j5, j6, z4 and z5 smooth. Measurements of setae as follows: j1 22 (21–22), j3 22 (20–24), j4 8 (7–8), j5 7 (6–8), j6 8 (7–9), J5 9 (8–10), z2 14 (12–15), z3 27 (26–28), z4 11 (11–12), z5 9 (8–9), Z4 47 (44–48), Z5 54 (51–57), s4 63 (59–68), s6 64 (58–68) and r3 32 (31–33). Peritreme long, extending to level of setae j1.Venter (Figures 7b, 8b). Sternal shield smooth, lightly sclerotized, with three pairs of setae (st1, st2 and st3) and two pairs of poroids (iv1 and iv2); distance between st1- st3 56 (54–57), st2- st2 55 (52–58); metasternal shields not visible, metasternal setae st4 and pair of poroids (iv3) on soft integument; genital shield smooth, width at level of st5 66 (62–68). Ventrianal shield smooth, elongated, with three pairs of pre-anal setae (JV1, JV2 and ZV2), one pair of paraanal (Pa) and one postanal seta (Pst), preanal pores gv3 visible in some specimens. Length of ventrianal shield 94 (87–97), width at level of setae ZV2 48 (44–50), width at level of anus 48 (46–51). Setae ZV1, ZV3, JV5 and five pairs of poroids on integument surrounding ventrianal shield. Setae JV5 thick, and strongly serrated, 41 (38–43) in length.

Chelicera (Figures 7c, 8c). Fixed digit 21 (20–22) long with four teeth and pilus dentilis; movable digit 22 (21–22) long with one tooth.

Spermatheca (Figures 7d, 8d). Calyx short, v-shaped 10 (10–11) in length, atrium large, bulbous. Major duct broad, minor duct not visible.

Legs (Figures 7e, 8e). Length of legs (excluding pretarsus): leg I 260 (252–268); leg II 220 (215–225); leg III 224 (218–228); leg IV 388 (376–397). Chaetotaxy as follows: Leg I; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 2 3/1 2/2 2, genu 2 2/1 2/1 2, tibia 2 2/1 2/1 2. Leg II; coxa 0 0/1 0/1 0, trochanter 1 0/1 0/2 1, femur 2 3/1 2/1 1, genu 2 2/0 2/0 1, tibia 1 2/1 1/1 1. Leg III; coxa 0 0/1 0/1 0, trochanter 1 1/1 0/2 0, femur 1 2/1 1/0 1, genu 1 2/0 2/0 1, tibia 1 1/1 2/1 1. Leg IV; coxa 0 0/1 0/0 0, trochanter 1 1/1 0/2 0, femur 1 2/1 1/0 1, genu 1 2/0 2/1 1, tibia 1 1/0 2/1 1. Leg IV with four macrosetae; SgeIV, StiIV and StIV with membranous large knobs 9 (9–10), 35 (32–39) and 21 (20–22) in length, respectively, and that on telotarsus thicker than other setae on the same segment with blunt tip, 19 (18–19) in length.

World Distribution — India (Gupta 1977) and Maldives (this study).

RemarksPhytoseius meyerae was described by Gupta (1977) from Tura, Meghalaya, India. Morphological characters and measurements of the Maldivian material are almost identical to that of the original description and the redescriptions (Gupta 1985, 1986, 2003). However, seta s4 in the Maldivian material is slightly longer compared to those of the original and the redescriptions [(63 (59–68) vs 44–45]. We consider this difference as a flaw of the descriptions by Gupta (1985, 1986, 2003), as the seta s4 almost reaching the base of setae s6 in Indian material, similar to the Maldivian material.

In addition, measurements of seta Z5 appear to be longer [54 (51–57)] in Maldivian material when compared to that provided in the original description (37). However, measurements of this seta fall into range provided in the subsequent redescriptions by the same author (Gupta 1985, 1986, 2003). This species appears to be close to the several other Phytoseius such as P. coheni Swirski & Shechter, 1961, P. brevicrinis Swirski & Shechter, 1961, P. taiyushani Swirski & Shechter, 1961 and P. rimandoi Corpuz, 1966, all has priority over P. meyerae. However, it can be separated from the aforementioned species by the combination of following characters, lengths of dorsal setae and macrosetae on genu IV, the length and the shape of ventral seta JV5, the shape of distal macroseta on telotarsus IV.

Discussion

Phytoseiid mites are considered to be one of the most important groups of predators for biological control of spider mites, and small soft bodied insects such as thrips, and whiteflies (McMurtry et al. 2013). Although previous studies have been documented a rich phytoseiid mite fauna including series of endemic species in its neighbouring countries such as India and Sri Lanka, nothing was known about native phytoseiid fauna in Maldives, an archipelagic country located in the Indian Ocean (Gupta 2003; Moraes et al. 2004; Khaustov et al. 2021; Kar and Karmakar 2022).

In this study, we reported six species belongs to four genera for the first time in Maldives. When its volcanic origin and isolated geographic position along with previous records of phytoseiids in its neighbouring countries as well as findings of the current work are considered together, it is clear that Maldives hold a special interest for further discoveries of phytoseiid mites.

Acknowledgements

This study was supported by the cooperative agreement from the Russian Ministry of Science and Higher Education, grant number: FEW-2021-0004; Ismail Döker was supported by the Cukurova University Scientific Projects Foundation Units, grant number: FAY-2022-14495.



References

  1. Athias-Henriot C. 1975. Nouvelles notes sur les Amblyseiini. II. Le relevé organotaxique de la face dorsale adulte (Gamasides, protoadéniques, Phytoseiidae). Acarologia, 17: 20-29.
  2. Chant D.A. 1960. Descriptions of five new species of mites from India (Acarina: Phytoseiidae, Aceosejidae). Can. Entomol., 92: 58-65. https://doi.org/10.4039/Ent9258-1
  3. Chant D.A, McMurtry J.A. 2007. Illustrated keys and diagnoses for the genera and subgenera of the Phytoseiidae of the world (Acari: Mesostigmata). West Bloomfield: Indira Publishing House. pp. 219.
  4. Chant D.A., Yoshida-Shaul E. 1991. Adult ventral setal patterns in the family Phytoseiidae (Acari: Gamasina). Int. J. Acarol., 17: 187-199. https://doi.org/10.1080/01647959108683906
  5. Corpuz L.A. 1966. Seven new species of mites of the genera Typhlodromus and Phytoseius (Phytoseiidae: Acarina). Philip. Agric., 50: 729-738.
  6. Demite P.R., de Moraes G.J., McMurtry J.A., Denmark H.A., Castilho R.C. 2022. Phytoseiidae Database. Available from: www.lea.esalq.usp.br/phytoseiidae (accessed 23 June 2022).
  7. Denmark H.A., Evans G.A. 2011. Phytoseiidae of North America and Hawaii (Acari: Mesostigmata). West Bloomfield: Indira Publishing House. pp. 451.
  8. Denmark H.A., Muma M.H. 1989. A revision of the genus Amblyseius Berlese, 1914 (Acari: Phytoseiidae). Occasional Papers of the Florida State Collection of Arthropods. 4, 149 pp.
  9. Evans G.O. 1963. Observations on the chaetotaxy of the legs in the free-living Gamasina (Acari: Mesostigmata). Bull. Br. Mus. Nat. Hist. Zool., 10: 275-303. https://doi.org/10.5962/bhl.part.20528
  10. Ferragut F., Baumann J. 2019. New phytoeiid mites (Mesostigmata: Phytoseiidae) of Mauritius, with the description of two new species. Syst. Appl. Acarol., 24: 825-856. https://doi.org/10.11158/saa.24.5.8
  11. Furtado I.P., Kreiter S., Moraes G.J de, Tixier M.-S., Flechtmann C.H.W., Knapp M. 2005. Plant mites (Acari) from Northeastern Brazil, with description of two new species of the family Phytoseiidae (Mesostigmata). Acarologia, 45: 131-143.
  12. Gondim Jr MGC, Moraes GJ de 2001. Phytoseiid mites (Acari: Phytoseiidae) associated with palm trees (Arecaceae) in Brazil. Syst. Appl. Acarol., 6: 65-94. https://doi.org/10.11158/saa.6.1.11
  13. Gupta SK. 1977. New species and records of Typhlodromus and Phytoseius from eastern India (Acarina: Phytoseiidae). Indian J. Acarol., 2: 1-11.
  14. Gupta S.K. 1985. Plant mites of India. Zooogical Survey of India Handbook Series, Calcutta, 5: 1-520.
  15. Gupta S.K. 1986. Fauna of India (Acari: Mesostigmata) Family Phytoseiidae. Calcutta, India: Zoological Survey of India. pp. 350.
  16. Gupta S.K. 2003. A monograph on plant inhabiting predatory mites of India. Pat II: Order: Mesostigmata. Memoirs, 20: 1-185.
  17. Kar A., Karmakar K. 2022. Seven new species of phytoseiid mites (Acari: Mesostigmata) from Tripura, northeastern India. Zootaxa, 5120: 213-241. https://doi.org/10.11646/zootaxa.5120.2.3
  18. Karmakar K, Bhowmik S, Sherpa, C. 2017. Description of five new species and re-description of two species of Amblyseius (Acari: Phytoseiidae) from West Bengal, India. Zootaxa, 4311: 39-61. https://doi.org/10.11646/zootaxa.4311.1.3
  19. Khaustov V., Doker I., Joharchi O., Ermilov S.G. 2021. A new species of Proprioseiulus Muma (Acari: Phytoseiidae) from Sri Lanka with a key to world species. Syst. Appl. Acarol., 26: 464-473. https://doi.org/10.11158/saa.26.2.10
  20. Kreiter S., Abo-Shnaf R.I.A. 2020. New records of phytoseiid mites from Mauritius Island (Acari: Mesostigmata). Acarologia, 60: 520-545. https://doi.org/10.24349/acarologia/20204382
  21. Kreiter S., Payet R.-M., Douin M., Fontaine O., Fillâtre J., Le Bellec F. 2020. Phytoseiidae of La Réunion Island (Acari: Mesostigmata): three new species and two males described, new synonymies, and new records. Acarologia, 60: 111-195. https://doi.org/10.24349/acarologia/20204361
  22. Lawson-Balagbo L.M., Gondim Jr. M.G.C., Moraes G.J. de, Hanna R., Schausberger P. 2008. Exploration of the acarine fauna on coconut palm in Brazil with emphasis on Aceria guerreronis (Acari: Eriophyidae) and its natural enemies. Bull. Entomol. Res., 98: 83-96. https://doi.org/10.1017/S0007485307005421
  23. Liao L.-R., Ho C.-C., Lee H.-C., Ko C.-C. 2020. Phytoseiidae of Taiwan (Acari: Mesostigmata). Taipei, Taiwan: National Taiwan University Press. pp. 538.
  24. Lindquist E.E., Evans G.O. 1965. Taxonomic concepts in the Ascidae, with a modified setal nomenclature for the idiosoma of the Gamasina (Acarina: Mesostigmata). Mem. Ent. Soc. Can., 47: 1-64. https://doi.org/10.4039/entm9747fv
  25. Lofego A.C., Demite P.R., Moraes G.J. de, Kishimoto R.G. 2009. Phytoseiid mites on grasses in Brazil (Acari: Phytoseiidae). Zootaxa, 2240: 41-59.
  26. McMurtry J.A., Moraes G.J. de, Famah-Sourassou N. 2013. Revision of the lifestyles of phytoseiid mites (Acari: Phytoseiidae) and implications for biological control strategies. Syst. Appl. Acarol., 18: 297-320. https://doi.org/10.11158/saa.18.4.1
  27. Moraes G.J. de, Lopes P.C., Fernando C.P. 2004. Phytoseiid mite (Acari: Phytoseiidae) of coconut growing areas in Sri Lanka, with descriptions of three new species. J. Acarol. Soc. Jap., 13: 141-160. https://doi.org/10.2300/acari.13.141
  28. Moraes G.J. de, McMurtry J.A., Yaninek J.S. 1989. Some phytoseiid mites (Acari, Phytoseiidae) from tropical Africa with description of a new species. Int. J. Acarol., 15: 95-102. https://doi.org/10.1080/01647958908683830
  29. Moraes G.J de, Castro T.M.G de, Kreiter S., Quilici S., Gondim Jr. M.G.C, Sá L.A. 2012. Search for natural enemies of Raoiella indica Hirst in Réunion Island (Indian Ocean). Acarologia, 52: 129-134. https://doi.org/10.1051/acarologia/20122043
  30. Muma M.H. 1955. Phytoseiidae (Acarina) associated with citrus in Florida. Ann. Entomol. Soc. Am., 48: 262-272. https://doi.org/10.1093/aesa/48.4.262
  31. Muma M.H. 1967. New Phytoseiidae (Acarina: Mesostigmata) from southern Asia. Fla. Entomol., 50: 267-280. https://doi.org/10.2307/3493156
  32. Navia D., Domingos C.A., Mendonça R.S., Ferragut F., Rodrigues M.A.N., de Morais E.G.F., Tixier M.-S., Gondim Jr. M.G.C. 2014. Reproductive compatibility and genetic and morphometric variability among populations of the predatory mite, Amblyseius largoensis (Acari: Phytoseiidae), from Indian Ocean Islands and the Americas. Biol. Cont., 72: 17-29. https://doi.org/10.1016/j.biocontrol.2014.01.011
  33. Prasad V. 1968. Some Typhlodromus mites from Hawaii. Ann. Entomol. Soc. Am., 61: 1369-1372. https://doi.org/10.1093/aesa/61.6.1369
  34. Pritchard A.E., Baker E.W. 1962. Mites of the family Phytoseiidae from Central Africa, with remarks on genera of the world. Hilgardia, 33: 205-309. https://doi.org/10.3733/hilg.v33n07p205
  35. Rowell H.L., Chant D.A., Hansell R.I.C. 1978. The determination of setal homologies and setal patterns on the dorsal shield in the family Phytoseiidae (Acarina: Mesostigmata). Can. Entomol., 110: 859-876. https://doi.org/10.4039/Ent110859-8
  36. Schicha E. 1987. Phytoseiidae of Australia and neighboring areas. West Bloomfield: Indira Publishing House. pp. 187.
  37. Schicha E., Corpuz-Raros L.A. 1992. Phytoseiidae of the Philippines. West Bloomfield: Indira Publishing House. pp. 190.
  38. Schicha E., McMurtry J. 1986. Two new and two known species of Typhlodromus Scheuten (Acari: Phytoseiidae) from Australia. J. Aust. Entomol. Soc. 25: 177-183. https://doi.org/10.1111/j.1440-6055.1986.tb01100.x
  39. Swirski E., Amitai S. 1967. An undescribed Typhlodromus (Acarina: Phytoseiidae) from Israel. Isr. J. Agric. Res., 17:53-56.
  40. Swirski E., Shechter R. 1961. Some phytoseiid mites (Acarina: Phytoseiidae) of Hong-Kong, with a description of a new genus and seven new species. Isr. J. Agric. Res., 11: 97-117.
  41. Zannou I.D., Moraes G.J. de, Ueckermann E.A., Oliveira A.R., Yaninek J.S., Hanna R. 2007. Phytoseiid mites of the subtribe Amblyseiina (Acari: Phytoseiidae: Amblyseiini) from s https://doi.org/10.11646/zootaxa.1550.1.1
